Frame
Alpha Smooth Aluminum, Bosch Compact PowerTube, internal cable routing, post-mount disk, 135X5mm QR
-
Fork
Verve alloy, threaded steel steerer, ThruSkew QR
-
Hub front
Formula DC-20, alloy, 6-bolt, 5x100mm QR
-
Skewer front
132x5mm QR, ThruSkew
-
Hub rear
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR
-
Skewer rear
155x5mm QR
-
Rim
Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve
-
Spokes
14g stainless steel, black
-
Tire
Bontrager H2 Comp, wire bead, 30 tpi, 27.5x2.00"
-
Max tire size
27.5x2.00" with or without fenders
-
Battery
Bosch CompactTube 400Wh
-
Charger
Bosch standard 2A, 110V, smart system
-
Computer
Bosch Purion 200
-
Motor
Bosch Active Line Plus
-
Shifter
Shimano U4000, 9 speed
-
Rear derailleur
Shimano CUES U4000
-
Crank
ProWheel alloy, 170mm length
-
Chainring
ProWheel 38T narrow/wide steel, w/alloy guard
-
Cassette
Shimano CUES LG300, LINKGLIDE, 11-36, 9 speed
-
Chain
Shimano LG500, 9/10/11 speed
-
Pedal
Bontrager City pedals
-
Max chainring size
1x: 40T
-
Saddle
Bontrager Boulevard
-
Seatpost
Alloy, suspension, 31.6mm, 300mm length
-
Handlebar
Bar/stem w/ light mount
-
Grips
Bontrager Satellite Elite, alloy lock-on
-
Stem
Integrated stem, 35mm clamp
-
Brake
Shimano MT200 hydraulic disk
-
Brake rotor
Shimano RT26, 6-bolt, 160mm
-
Brake Set
Shimano MT200 hydraulic disk
-
Rotor size
Max brake rotor sizes: 160mm front & rear
-
Light
Size: S, M, L<br>Spanninga SOLO for e-bike, taillight
-
Light
Size: S, M, L<br>Herrmans MR5-E, 140lumen, 40lux, LED, headlight
-
Kickstand
Alloy, rear-mount kickstand
-
Cargo rack
MIK-compatible alloy rear rack
-
Fender
SKS wide, plastic
-
Weight
M - 23.50 kg / 51.81 lbs
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
