Frame
Alpha Platinum Aluminum, tapered head tube, ZS headset, internal derailleur & dropper post routing, ISCG 05, threaded BB, UDH, 148x12mm thru axle
Fork
Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt axle, 150mm travel
Fork Size
XL, L, M, ML
Hub front
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle
Hub rear
Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano freehub, Boost148, 12mm thru axle
Skewer rear
Bontrager Switch thru axle, removable lever
Rim
Bontrager Line TLR 30, Tubeless Ready, 28-hole, Presta valve
Tire
Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5x2.50''
Tire Size
XL, L, M, ML
Tire part
Bontrager TLR sealant, 6oz
Rim strip
Bontrager TLR
Max tire size
Frame: 29x2.60", Fork: See manufacturer
Shifter
Shimano Deore M6100, 12 speed
Rear derailleur
Shimano Deore M6100, long cage
Crank
Shimano MT512, 30T ring, 55mm chainline, 170mm length
Bottom bracket
Shimano BB-MT501 BSA
Cassette
Shimano Deore M6100, 10-51, 12 speed
Chain
Shimano Deore M6100, 12 speed
Max chainring size
1x: 34T, min 28T
Saddle
Bontrager Verse P3, steel rails
Seatpost
TranzX JD-YSI34, 150mm travel, internal routing, 31.6mm, 456mm length
Seatpost Size
M, ML
Seatpost Size
XL, L
Handlebar
Bontrager alloy, 31.8mm, 15mm rise, 750mm width
Handlebar Size
XL, L, M, ML
Grips
Trek Line Comp, nylon lock-on
Stem
Bontrager Comp, 31.8mm, 35mm length
Stem Size
XL, L, M, ML
Headset
FSA Orbit, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom, 1.5 crown
Brake
Shimano 4-piston hydraulic disk, M6100 lever, M6120 caliper
Brake rotor
Shimano RT66, 6-bolt, 180mm
Brake rotor
Shimano RT66, 6-bolt, 203mm
Rotor size
Max brake rotor sizes - Frame: 203mm, min 180mm, Fork: see fork manufacturer
Weight
M - 14.18 kg / 31.27 lbs (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
